2-axis load cell Fx/Fy biaxial force sensor

Model:                        F2H

Capacity:                   20/50/100/200kg

Material:                     Stainless steel

Load direction:           Fx/Fy

Rated output:              1.5mV/V

Non-repeatability:      0.1% of R.O.

Excitation:                  3~12V

Other:                         Custom-design service


Biaxial load cell F2H is made from stainless steel based on strain gauge technology offering 20kg / 50kg / 100kg / 200kg four rated capacities for Fx/Fy two-dimensional force measurement. Each axis can be loaded in both tension and compression direction. 2-axis force sensor F2H can work with our 2-channel load cell amplifier LC2A to deliver 0-5V / 0-10V / 4-20mA output that is proportional to the force applied. Model F2H can be modified or customized upon request.
