Product > Tension compression load cell

Flange type tension compression load cell 0-50kg

Model:                        FXFA

Capacity:                    5/10/20/30/50kg

Material:                    Stainless steel

Load direction:           Traction/compression

Rated output:              1.0mV/V

Non-repeatability:      0.1% of R.O.

Excitation:                  3~15V

Mounting:                  Flange-to-Flange


Flange mounted load cell FXFA is made from stainless steel based on strain gauge technology intended for both traction and compression force measurement. Tension/compression sensor FXFA offers 0-5kg / 0-10kg / 0-20kg / 0-30kg / 0-50kg five rated measuring ranges to choose from. Force transducer FXFA features 1000ohms high resistance for lower power consumption and better stability, it can be modified or customized upon request.

Searching keywords:
Flange type load cell,tension compression sensor
