Stainless steel shear beam load cell 0-20klb

Model:                        FHSF

Capacity:                    0~20klb

Material:                     Stainless steel

Type:                         Shear beam load cell

Rated output:              3.0mV/V

Non-repeatability:      0.02% of R.O.

Excitation:                  3~15V

Usage:                        Hopper weighing


Single ended shear beam load cell FHSF is made of stainless steel and IP67 hermetically sealed to deliver long-term stability and durability for weighing applications even in harsh conditions. Single ended beam load cell FHSF is temperature compensated and offers 250lb / 500lb / 1klb / 1.5klb / 2klb / 2.5klb / 3klb / 5klb / 7.5klb / 10klb / 15klb / 20klb rated capacities to choose from, high accuracy with maximum 0.02% non-linearity of the full scale, unified 3.0mV/V rated output, you may find weight transducer FHSF a good option for applications such as hopper scales, vessel weighing system, pallet scales,etc.
