Single point load cell for packaging machine

Model:                        FHQ

Capacity:                    0-50kg

Material:                     Aluminum alloy

Type:                         Single point load cell

Rated output:              1.9±10%mV/V

Non-repeatability:      0.015% of R.O.

Excitation:                  3~15V

Usage:                        Packaging machine


High accuracy single point load cell FHQ is strain gauge based with maximum 0.02% non-linearity of the full scale, offering 3kg / 5kg / 8kg / 10kg / 20kg / 30kg / 50kg seven rated capacities to choose from. Load sensor FHQ is P65 sealed and comes with a 2-meter-long 4-core shielded cable, weight transducer FHQ is temperature compensated and corner trimmed for platform sizes up to 450x450mm, which makes it suitable for off-center load measurement in a wide temperate range. You may find model FHQ applicable for packaging machines, electronic scales, auto filling machines and so on.
