0-500kg Digital load cell with RS485 output

Model:                        FDNT

Capacity:                    100/200/300/500kg

Material:                     Aluminum alloy

Type:                          Digital load cell

Output:                       RS485

Non-repeatability:      0.01% of R.O.

Excitation:                  5~12V DC

Usage:                        Waste management scales


Digital load cell with RS485 output (Model FDNT) utilizes a microprocessor inside of the sensor to convert the analog signal from the wheatstone bridge to digital signal, which is less susceptible to interference from radio frequencies, electromagnetics, temperature,etc., this makes digital load cells more stable and accurate compared to analog load cells. Load transducer FDNT supports RS485 Modbus RTU protocol with 0-100kg / 0-200kg / 0-300kg / 0-500kg four rated measuring ranges to choose from, off-center load compensated for platform sizes up to 800x800mm. Weight sensor FDNT is constructed from aluminium and environmentally sealed with potting compound to ensure durability. Typical applications of model FDNT are for example platform scales, automated weighing stations, food packaging machines, Intelligent warehouse weighing system, waste management scales and so on.
