Product > Beam load cell

Off center load cell high accuracy weight sensor

Model:                        FHN

Capacity:                    3kg~100kg

Material:                     Aluminum alloy

Type:                         Single point load cell

Rated output:              2.0±10%mV/V

Non-repeatability:      0.015% of R.O.

Excitation:                  3~15V

Other:                        Off-center load cell


Single point load cell FHN is made of aluminum based on strain gauge technology to deliver maximum 0.02% non-linearity of full scale, offered in 3kg / 5kg / 8kg / 10kg / 15kg / 20kg / 30kg / 50kg / 100kg nine rated capacities to choose from. Load cell sensor FHN is sealed to IP65 and comes with a 6-core shielded cable in 3m length, weight transducer FHN is temperature compensated and corner trimmed for platform sizes up to 400x400mm, which makes sensor FHN suitable for off-center load measurement in a wide temperature range. You may find model FHN applicable for applications such as green plants weight monitoring, platform scales, food packaging machines and so on.
