Non-contact torque sensor shaft torque measurement

    Model:              FYTS

Capacity:              0.5/1/2/3NM

Material:               Aluminum alloy

Torque direction:     CW&CCW

Rated output:        5kHz~15kHz

Non-repeatability:   0.2% F.S.

Excitation:            ±15V DC

Other:                   Customizable

Features:

dc motor torque measurement

--Non-contact rotary torque transducer

--Shaft to shaft configuration,compact size

--Torque measurement and speed measurement

--Rotating speed up to 6000RPM

shaft torque measurement

Dimensions:
Searching keywords:
Non-contact rotary torque sensor,shaft torque sensor,rotating shaft torque measurement
